S25
This rock drill is used for development end drilling. This hard-hitting powerful machine is suitable to be used in any drilling operation where the operator is able to adopt a standing upright posture.
Air legs and air leg extensions are also available for both machines.
| Description | S25 Rock Drill (Seco Equivalent) | S215 Rock Drill (Seco Equivalent) |
| Part No | 258592 | 158592 |
| Est. Weight (kg) | 31kg | 22.6kg |
| Length incl. Drill steel retainer (mm) | 760 | 730 |
| Drill steel chuck hex (mm) | 22mm or 25mm x 159 | 22mm or 25mm x 159 |
| Bore | 79mm | 68mm |
| Stroke | 70mm | 55mm |
| Blows/Min | 2000 @ 500 kPa | 2175 @ 500 kPa |
| Air connection | ¾” BSP | ¾” BSP |
| Water connection | ½” BSP | ½” BSP |
| Est. Noise Level | 100.3 dB (A) | 100.3 dB (A) |
| Air Consumption (cfm) | 145 @ 500 kPa | 116.5 @ 500 kPa |
| Water Consumption(lt/min) | 7.6 @ 450 kPa | 7.6 @ 450 kPa |
